16,000LPH Borehole Brackish Water Purification Systems Industrial Reverse Osmosis System
PRODUCT DESCRIPTION
16,000LPH Borehole Brackish Water Purification Systems are capable of removing salts, as well as other impurities such as bacteria,sugars, proteins, dyes and constituents having a molecular weight greater than 150- 250 Daltons. Our commercial BWRO systems are strategically designed to be energy efficient and environmentally friendly while producing high-quality water.
Industrial Brackish Water Desalination Plant Capacity range between 48m3/hour to 7500m3/day. If you need smaller than this capacity please consult JuJinRo sales team.
If the water TDS is more than 1000ppm, we call this one as brackish water. Different source of science books defines brackish water TDS as different. But if water is not tap water and seawater, and TDS between 100 to 12000ppm, it can be called as brackish water.
PARAMETERS
| Feed Source | TapWater | WellWater | Surface Water | BrackishWater | |
| Feed SDI | <3 | <3 | <5 | <5 | |
| Max Element Recovery (%) | 19 | 17 | 15 | 13 | |
| Average System Flux (gfd) | 20 | 17 | 13 | 10 | |
| Max Feed Flow Rate per Element (gpm) | 2.5" Diameter | 6 | 6 | 6 | 6 |
| Max Feed Flow Rate per Element (gpm) | 4" Diameter | 14 | 14 | 14 | 14 |
| Max Feed Flow Rate per Element (gpm) | 8" Diameter | 75 | 70 | 55 | 60 |
| Min Concantrate Flow Rate per Element (gpm) | 2.5" Diameter | 1 | 1 | 1 | 1 |
| Min Concantrate Flow Rate per Element (gpm) | 4" Diameter | 3 | 3 | 3 | 3 |
| Min Concantrate Flow Rate per Element (gpm) | 8" Diameter | 14 | 14 | 14 | 14 |
This system's design is depend on customer raw water test report and application.
| Operation Specifications | ||
| • Max. feed water temperature: 42°C • Equipment upgrade for TDS over 5,000 ppm • Hydrogen Sulfide must be removed • Max. Silica Tolerance: 60 ppm @ 60% recovery | • Feed water TDS: 0-1,000, 3,000, 5,000 ppm • Operating pressure: 150 to 250 psi • pH tolerance range: 3-11 • Max. Iron content: 0.05 ppm | • Feed water pressure: 20 to 80 psi • Hardness over 1 GPG requires antiscalant dosing • Turbidity should be removed • Operate at higher TDS by lowering recovery |
PROCESSING
Raw water→ raw water tank(buyer supply)→raw water pump→laminated filter →activated carbon filter→chemical dosing system→security filter→high pressure pump→ro system→water supply point
All Brackish Water Treatment Plants are started from booster pump, it feeds raw water to pretreatment tanks. Depends on capacity pretreatment tank size and numbers can be changed. Because of High TDS (Total Dissolved Solid) we usually use FRP and Carbon Steel Tanks but we can check your raw water source analysis and we can suggest alternative material. If salt content and TDS high, because of the corrosion, we are using FRP or Carbon Steel material for pretreatment tanks.
Some parts function:
| Quartz sand filter: fill quarts sand inside, it can filter big particles impurities, suspended substances, colloids etc. |
| Activated carbon filter: fill activated carbon inside, to remove color, odor, residual chlorine and organics substances. |
| Security filter: fill PP filter cartridge inside, prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um. |
| Chemical dosing system: add antiscalant(buyer supply) , absorb Ca2+, Mg2+(main elements for composing scale), reduce hardness of raw water. |
| RO membrane: can remove particles, colloids, organic impurities, heavy metal ions, bacteria, virus, heat source etc. harmful substances and 99% dissolved salts. |
| UV sterilizer: for killing bacterial in water, be safe for drinking. |
| CIP system: its help to cleaning the RO membrane, so that it can be have long life span^^ |
Brackish RO systems require pre-treatment of which is always included in the sale unless the water is already being treated. Pre-treatment systems depend on the quality of water that is treated along with the application. Taking those two into account is how our engineers recommend the most appropriate pre/post treatment for the system. Components of pre/post treatment include multimedia and activated carbon filters along with water softeners and UV sterilizers. A chemical dosing system and/or a cleaning skid are also incorporated into the system.
Brackish reverse osmosis systems are equipped to purify water from rivers, lakes, wells, and the sea. With high pressure pumps, water is pressurized to pass through a finely pored semi-permeable membrane and filter the water. Around 99% of contaminants including salts, bacteria, and other particles are removed leaving the water in its most purified form. The system releases the purified (permeate) water from one stream and the reject filled with concentrated contaminants from another. Depending on the application of the water, post-treatment may be applied.
APPLICATION
The ideal applications for brackish reverse osmosis systems include:| • Rinse Water • Mining Industry • Chemical Blending • Laboratory • Beverage Production and Bottled Water • Spotless Car Wash System | •Ion Exchange Pre-treatment • Boiler Feed Water • Food and Beverage • Safe Drinking Water • Electronics • Plating Operations | • Ice Manufacturing • Power Plants • Metal Finishing • EDI Pre-treatment • Cooling Towers • Pharmaceutical |
To find the most appropriate system for your use, please have the following information ready:
1. Pure Water Production Capacity (L/day, L/Hour, GPD)
2. Feed Water TDS and Raw Water Analysis Report (prevent fouling and scaling problem)
3. Iron and Manganese must be removed before raw water enter to membrane of Brackish Water Desalination Plant
4. TSS (Total Suspended Solid) must remove before industrial Brackish Water Treatment Plant‘s membrane.
5. SDI (Silt Density Index) must be less than 3
6. Must be sure your water source does not have oil and grease
7. Chlorine must be removed before industrial Brackish Water RO Plant
8. Available electrical power voltage and phase
9. Layout of place for industrial Brackish Water RO Plant
Electrical Power of industrial Brackish Water RO Plant
For industrial Brackish Water Treatment Plant needs 220-380V/50Hz/60Hz. For bigger capacity, because of high pressure pump, it needs 380V 50/60Hz. As regards to your Brackish Water RO Plant machine design, we will check your electrical supply and decide fix power to you.
FEATURES
High Capacity of BWRO Systems
The KJ-300 series comes with many similar standard features as the KJ-200 series. However, the capacity of RO-300 is a main differentiator between the two. KJ-300 series is comprised of brackish reverse osmosis systems that can accommodate between 13,000 to 32,000 GPD with feed water TDS of 1000 ppm to 5000 ppm.
JuJinRO’s RO systems are capable of removing salts as well as other impurities such as bacteria, sugars, proteins, dyes and constituents having a molecular weight greater than 150-250 Dalton. In addition, these RO systems have the ability to remove color, iron, odor, hardness, sulfur, and chlorine while being economical and efficient through the usage of Dow Filmtec, Hydranautics, and Toray membranes (Our systems are made in the USA).
| Standard Futers | Available Options |
| Programmable PLC Control | Automatic Flush |
| Motor Starter | Ozone Generator |
| Raw Water Feeding/Booster Pump | UV Sterilizer |
| Stainless Steel Cartridge Filter Housing | Chemical Dosing |
| FRP Membrane Housing | pH control monitor |
| Mitsubishi Processor Control | ORP Control monitor |
| Low Pressure Switch | Remote Control |
| High Pressure Switch | Pretreatment System |
| Liquid filled pressure gauge | Post Deionization Unit |
| Stainless Steel 304 Frame | CIP Membrane cleaning system |
| Permeate Conductivity Monitor | Touch Screen Control |
| Raw Water Conductivity Monitor | Tank Level Switch |
| Membranes | Customer Logo |
| Control Valves | |
| Stainless Steel/UPVC Piping |
CUSTOMIZED CAPABILITY
JuJinRO supplies a full line of standard and fully customizable brackish reverse osmosis systems, all of which are engineered using advanced 3D computer modeling and process design software for accurate and customized solutions.
Regardless of the condition of your water supply, brackish type water is more difficult to treat due to the increased probability for changes in salinity over time. This occurrence ultimately affects water prices since energy usage is elevated and the treatment process is burdened as a result of an upward movement of salinity throughout the groundwater.
A significant aspect for the effective running of a brackish reverse osmosis system is the RO feedwater quality, which becomes resolved by the consistency of the water body and the success of the pretreatment process.
Compared to the KJ-200 Series, KJ-300 Series is displayed vertically and made with heavy-duty materials to withstand the higher capacity that it produces. For example, stainless steel piping is used in KJ-300 brackish reverse osmosis system. Whereas, the KJ-200 uses standard tubing. The high pressure pump is 316L stainless steel. Each pressure vessel has multi membrane, and the vessels are installed horizontally.
Ultra-high-quality water for specific applications and is customizable depending on the application and source of the water. Pure Aqua, Inc. takes pride in their ability to offer the most appropriate solution for any water treatment need.
